Advantages
1. Energy Efficiency - The Indoor Pool Air Source Heat Pump is very energy efficient, using up to 80% less energy than traditional pool heating systems. This means significant cost savings on the utility bill.
2. Reduced Carbon Footprint - As the Indoor Pool Air Source Heat Pump is an energy-efficient system, it reduces the carbon footprint and helps to preserve the environment.
3. Improved Indoor Air Quality - This system not only heats the pool but also provides additional benefits, such as improved indoor air quality. It helps to remove excess humidity from the air, making the indoor pool area comfortable and healthy.
4. Longevity and Durability - Indoor Pool Air Source Heat Pump is durable and long-lasting. It is designed to stand the test of time, meaning the owner does not need to replace it often.
5. Smart Control Technology - With advanced smart control technology, the system can be set to automatically turn on and off to maintain the desired temperature, ensuring maximum efficiency.
|
Product Model |
JM-03L-YS |
JM-O5L-YS |
JM-07L-YS |
JM-10L-YS |
JM12LYS |
JM25LYS |
JM30LYS |
JM50LYS |
JM60LYS |
|
Nominal cooling capacity(kW)/35℃ |
7.5 |
13.4 |
16.4 |
25 |
28.9 |
61.8 |
70.4 |
130 |
150 |
|
Nominal cooling power consumption(kW)/35℃ |
2.6 |
4 |
6.1 |
8 |
10.5 |
22.5 |
25.7 |
44.7 |
49.5 |
|
Rated heat production/heating(kW)/7℃ |
9.5 |
15.5 |
21.4 |
31 |
36.8 |
75.1 |
91 |
155 |
168 |
|
Rated heating power consumption(kW)/7℃ |
29 |
4.6 |
6.28 |
9.2 |
10.9 |
21.8 |
25.2 |
43.8 |
47.5 |
|
Nominal heat production/heating(kW)/-12℃ |
5.45 |
10 |
13.5 |
20 |
24 |
52.2 |
57 |
98 |
110 |
|
Nominal heating power consumption(kW)/-12℃ |
2.27 |
4.15 |
5.67 |
8.3 |
10 |
21.1 |
23.8 |
41.2 |
45.8 |
|
Maximum power consumption(kW) |
3.9 |
5.8 |
7.5 |
11.6 |
13 |
32 |
34 |
60 |
70 |
|
Max. current(A) |
18.5/8.0 |
32/11.0 |
14.2 |
22 |
24.8 |
55 |
57 |
110 |
130 |
|
Rated water discharge temperature(℃) |
45 |
45 |
45 |
45 |
45 |
45 |
45 |
45 |
45 |
|
Maximum outlet water temperature(℃) |
55 |
55 |
55 |
55 |
55 |
55 |
55 |
55 |
55 |
|
Rated hot water flow(㎡/h) |
1.4 |
2.4 |
3.2 |
4.8 |
5.6 |
11.8 |
13 |
23.6 |
25.6 |
|
Refrigerant |
R22 |
R22 |
R22 |
R22 |
R22 |
R410A |
R410A |
R410A |
R410A |
|
Compressor |
Copeland |
Copeland |
Copeland |
Copeland |
Copeland |
Copeland |
Danfoss |
Copeland |
Danfoss |
|
Water side heat exchanger |
High efficiency tank heat exchanger |
High efficiency tank heat exchanger |
High efficiency tank heat exchanger |
High efficiency tank heat exchanger |
High efficiency tank heat exchanger |
High efficiency tank heat exchanger |
High efficiency tank heat exchanger |
High efficiency tank heat exchanger |
High efficiency tank heat exchanger |
|
Power supply specification |
220V/380V |
220V/380V |
380V |
380V |
380V |
380V |
380V |
380V |
380V |
|
Interface size |
DN25 |
DN25 |
DN25 |
DN40 |
DN40 |
DN65 |
DN65 |
DN80 |
DN80 |
|
Ambient temperature range(℃) |
-35~48 |
-35~48 |
-35~48 |
-35~48 |
-35~48 |
-38~48 |
-38~48 |
-38~48 |
-38~48 |
|
Noise dB（A） |
60 |
63 |
66 |
67 |
68 |
70 |
72 |
73 |
75 |
|
Weight(kg) |
110 |
135 |
150 |
240 |
298 |
780 |
820 |
980 |
980 |
Indoor pool air source heat pump can have a significant impact on society：
Firstly, it reduces energy consumption and provides energy savings for homeowners, leading to reduced utility bills and increased cost savings. Secondly, with improved indoor air quality, the Indoor Pool Air Source Heat Pump creates a healthier and more comfortable environment for swimmers.
Thirdly, its reduced carbon footprint helps to preserve the environment and promotes sustainable living.
Indoor Pool Air Source Heat Pump is ideal for use in indoor swimming pools, whether for residential or commercial purposes. The system can be customized to adjust to different requirements and pool sizes, making it a versatile solution for various indoor pool applications.
In conclusion, Indoor Pool Air Source Heat Pump is a highly efficient and cost-effective solution for heating indoor swimming pools. With its energy-efficient features, smart control technology, longevity, and sustainability, the product has a significant impact on society. Its application and usage are versatile, making it a perfect choice for both residential and commercial swimming pools.
