Description
High Rhizome efficiency dryer is a new device that can take advantage of air source, which has been made the most of all over the world. Air source dryer is a Eco-friendly, High-efficiency heating equipment, used for drying agricultural products,marine products,vegetables ,fruits,nuts,Chinese medicinal materials,wood and so on. What's more, it also can be used in production line, such as leather production line, biscuit production line, fertilizer production line, instant noodle production line, pasture production line and other industrial production lines.
Its heat can be controlled by intelligent temperature controller, regulated between 12 and 85 degrees, It can avoid dust, rain and other external factors and improve drying speed. Air source heat pump dryer is an economical green product adapted to the concept of sustainable development. It can efficiently and perfectly replace the traditional energy sources such as Non-renewable Coal, oil, natural gas which are putting great stress on the environment.
|
Unit Model |
10PL |
12PL |
15PV |
25PV |
50PU |
|
|
Unit Model |
DKXRK-36Ⅱ/LH |
DKXRK-44Ⅱ/LH |
DKXRK-54Ⅱ/VH |
DKXRK-90Ⅱ/VH |
DKXRK-180Ⅱ/UH |
|
|
Power supply specifications |
380V/3N~50Hz |
380V/3N~50Hz |
380V/3N~50Hz |
380V/3N~50Hz |
380V/3N~50Hz |
|
|
Rated heating |
Nominal heat production(KW) |
36 |
46 |
54 |
90 |
180 |
|
Nominal heating input power (KW) |
8.7 |
10.9 |
12.8 |
21.4 |
42.8 |
|
|
Nominal current(A) |
19.6 |
21.8 |
25.6 |
42.8 |
85.6 |
|
|
Energy efficiency ratio (W/W) |
4.1 |
4.2 |
4.2 |
4.2 |
4.2 |
|
|
Outlet air temperature |
Rated heating return air temperature ℃ |
50 |
50 |
50 |
50 |
50 |
|
Maximum heating air outlet temperature ℃ |
75 |
75 |
75 |
75 |
75 |
|
|
Function |
Heating and drying |
Heating and drying |
Heating and drying |
Heating and drying |
Heating and drying |
|
|
Waterproof grade |
IPX4 |
IPX4 |
IPX4 |
IPX4 |
IPX4 |
|
|
Refrigerant (charge quantity) |
R134A |
2*5 |
2*5 |
2*5.2 |
2*10 |
4*10 |
|
Waterway side |
Type |
Set exchange |
Set exchange |
Set exchange |
Set exchange |
High efficiency tank |
|
Inlet and outlet water pipe size |
1.5"\DN40 internal teeth |
1.5"\DN40 internal teeth |
1"\DN25 internal teeth |
2"\DN50 internal teeth |
3"\DN80 internal teeth |
|
|
Circulating water flow rate(m³\h) |
7 |
7 |
5 |
15.5 |
31 |
|
|
Main pipe diameter |
PPR50/40 iron pipe |
PPR50/40 iron pipe |
PPR32/25 iron pipe |
63PPR/50 iron pipe |
90PPR/80 iron pipe |
|
|
Water-side pressure loss (kPa) |
60 |
60 |
50 |
85 |
85 |
|
|
Power cord specifications |
4 square copper wire |
4 square copper wire |
4 square copper wire |
10 square copper wire |
20 square copper wire |
|
|
Dimension |
1424*785*1210 |
1424*785*1210 |
1600*920*2000 |
2030*1100*2120 |
2300*1300*2390 |
|
|
Net weight of the unit(kg) |
305 |
340 |
200 |
730 |
1500 |
|
|
Gross weight of the unit(kg) |
340 |
380 |
230 |
780 |
1550 |
|
|
Operating noise(dB(A)) |
<65dB(A) |
<65dB(A) |
<65dB(A) |
<72dB(A) |
<78dB(A) |
|
|
Remarks |
1. Rated test conditions: ambient dry and wet bulb temperature is 20℃ /15℃ unit return air 50℃/70%. |
|||||
Working Principle
High Rhizome efficiency dryer constant temperature dehumidifier is a new type of high-efficiency energy-saving dryer. Its working principle is that according to the principle of reverse Carnot cycle, the evaporator absorbs heat from the air with a small amount of electric energy, which is compressed by the compressor and then released by the heat exchanger (condenser). The heat generated by the heat exchanger (condenser) is sent to the drying room by the fan, which provides continuous and stable hot air for the drying room, and can heat the drying medium to 55ºC ~ 70ºC to heat the materials.
